Orifice Flange

Orifice Flanges are used with orifice meters for the purpose of measuring the flow rate of either liquids or gases in the respective pipeline.  Orifice flanges generally come with either raised faces or RTJ (Ring Type Joint) facings.They are,for all intensive purposes,the same as weld neck and slip-on flanges with extra machining.They have modifications of radial tapped holes in the flange ring fo ...
  • PRODUCT DETAIL

Orifice Flanges are used with orifice meters for the purpose of measuring the flow rate of either liquids or gases in the respective pipeline.  Orifice flanges generally come with either raised faces or RTJ (Ring Type Joint) facings.They are,for all intensive purposes,the same as weld neck and slip-on flanges with extra machining.They have modifications of radial tapped holes in the flange ring for meter connections and orifice plate carriers for the reason of fitting meter connections.The additional bolts act as a jack to allow the separation of the two flanges to change the orifice plate or for other inspection services.(Know more about orifice flange)

Size

Orifice flange:1″-24″

DN25-DN600

Pressure

America Series:Class 150 ,Class 300, Class 600, Class 900A ,Class 1500,Class 2500.

Europe Series:PN2.5,PN6,PN10,PN16,PN25,PN40,PN63,PN100,PN160,PN250,PN320,PN400.

Flange Facing Types

America Series: Flat face(FF),Raised face(RF),Tongue(T),Groove(G),Female(F),Male(M),Ring type joints face(RJ/RTJ)

Europe Series: Type A(Flat Face),Type B(Raised Face),Type C(Tongue),Type D(Groove),Type E(Spigot),Type F(Recess),Type G(O-Ring Spigot),Type H(O-Ring Groove)

Materials

Stainless steel: ASTM/ASME A182 F304-304L-304H-304LN-304N

ASTM/ASME A182 F316-316L-316H-316LN-316N-316Ti

ASTM/ASME A182 F321-321H, F347-347H, F310-310H, F904-904H

Standards

ASME ANSI B16.36.

API 605,API 6L.

MSS SP 44

CSA Z245.12

EN1092-1,EN1759-1.

DIN2630,DIN2631,DIN2632,DIN2633,DIN2634,DIN2635,DIN2636,DIN2637,DIN2638.

BS1560,BS 4504,BS 10.

AFNOR NF E29-200-1

ISO7005-1

AS2129

JIS B2220

UNI 2276. UNI 2277.UNI 2278 .UNI 6089 .UNI 6090

Industrial Processes

Die forging,Machining.

Application for Orifice flanges

Naturalgas,chemical,petroleum,shipbuilding,marine,paper making,metallurgy,electric,power,boiler etc.

Hebei Haihao Group,as a first class manufacturer of orifice flanges in China,supply a variety of steel flanges to satisfy our customers’ specific requirements,which include different size,different schedule,different pressure and different finish faces.Our products are produced strictly according to the required standard.Our raw material for orifice flanges all are purchased from big steel companies which can make sure the material in a high quality.
